AD-SYSTEMS

[I.Flex Series] i.Sotto1

i.Sotto1


Applications



 • Shops and offices

 • Bars, museums, restaurants

 • Permanent installation

 • Scratch resistant paint



Features + Benefits



 • 3.5" woofer with 1' voice coil

 • High power handling with 30W AES/ 60W Program Power

 • 90° circular Dispersion

 • Scratch resistant paint



Specsheet





 Type

i.Sotto1

 Enclosure

Wood with scratch resistant coating

 Basic layout

sealed enclosure

 Colour

black and white:RAL standard colours on request

 Frequency Response(-3 dB)

92 Hz - 19kHz

 Power handling RMS | peak

30 W RMS | 60W Program I 100 W Peak

 Nominal Impedance

Ω

 Dispersion pattern(-6 dB)

90° circular

 Sensitivity 1W @ 1m

88 dB(full space)

 SPLmax

110 dB (SPL peak @ 1m)

 Connectors

Clip Connector

 Dimensions (w x h x d)

102 x 102 x 103 mm

 net weight

750 g (without bracket)

 Accessories

Bracket included
